Biến tần hòa lưới Growatt 8000MTL-S 8kW 1 Pha 220V
Mã SP: 8000MTL-S 8kW
SKU: 8000MTL-S
Nhà sản xuất: Growatt
Công suất: 8kW
Điện áp ngõ ra: 1 Pha 220V
Loại: 2 MPPT
Chất lượng: Mới 100%
Bảo hành: 5 năm
Chứng từ: CO/CQ, hóa đơn VAT
Nhà sản xuất: Growatt
Công suất: 8kW
Điện áp ngõ ra: 1 Pha 220V
Loại: 2 MPPT
Chất lượng: Mới 100%
Bảo hành: 5 năm
Chứng từ: CO/CQ, hóa đơn VAT
Giá: Giá: Liên hệ
| Model | 8000MTL-S |
| Input Data | |
| Max. recommended PV power (for module SIC) | 10500W |
| Max. DC voltage | 550V |
| Start voltage | 100V |
| Nominal voltage | 360V |
| MPP voltage range | 70-550 |
| No. of MPP trackers | 2 |
| No. of PV strings per MPP trackers | 2/1 |
| Max. Input current per MPP trackers | 2*12.5A/12.5A |
| Max. short-circuit current per MPP trackers | 32A/16A |
| DC overvoltage category | Category ll |
| Output (AC) | |
| AC nominal power | 8.2kW |
| Max. AC apparent power | 8.2kVA |
| Nominal AC voltage/range | 230/160-300V |
| AC grid frequency/range | 50-60Hz/44-55Hz;54-65Hz |
| Max. output current | 35.7A |
| Power factor(@nominal power) | >0.99 |
| Adjustable power factor | 0.8Ieading… 0.8Iagging |
| THDI | <3% |
| AC grid connection type | Single phase |
| AC overvoltage category | Category III |
| Efficiency | |
| Max. efficiency | 98.40% |
| Euro-eta | 97.90% |
| Protection Devices | |
| DC reverse-polarity protection | yes |
| DC switch | yes |
| DC Surge protection | Type III |
| Insulation resistance monitoring | yes |
| AC surge protection | Type III |
| AC short-circuit protection | yes |
| Ground fault monitoring | yes |
| Grid monitoring | yes |
| Anti-islanding protection | yes |
| Residual-current monitoring unit | yes |
| General Data | |
| Dimensions (W/ H / D) in mm | 419x355x185mm |
| Weight | 18.3 kg |
| Operating temperature range | – 25 °C +60 °C |
| Noise emission (typical) | < 25 dB(A) |
| Altitude | 3000m |
| Internal consumption at night | <0.5W |
| Topology | transformerless |
| Cooling | Natural convection |
| Protection degree | IP65 |
| Relative humidity | 0-100% |
| DC connection | VP-D4/MC4(Opfional) |
| AC connection | AC connector |
| Features | |
| Display | LCD+ LED |
| R5485/R5232 | Integrated |
| WIFI/GPRS/4G/LAN/ RE | Optional |
| Warranty:5/10 years | Yes/ Optional |
